Akuvox - S567W
10" IP Indoor Touchscreen Answering Panel with WiFi & Bluetooth
Product Description
The Akuvox S567W 10'' door intercom answering panel is their latest flagship device for door-to-door communication and access control in apartment living and shared office / co-working environments.
Running on the latest Android 12 operating system and equipped with Wifi 6 technology, the Akuvox S567W answering panel is ideal for integration as part of smart home living and access control systems in shared housing / multi-dwelling unit apartment buildings.
- Android 12 operating system supports integration with smart home living systems and flexibility to install 3rd-party Android applications and control other 3rd-party IP-connected ‘smart home’ devices such as lighting, heating, curtains etc.
- High performance audio supported by on-board dual microphones and 4 x internal loudspeakers.
- Built-in voice assistant supports hands-free answering of intercom calls and door unlocking.
- High resolution live video streaming of door intercom and surveillance cameras, as well as high performance video streaming from video apps such as YouTube, etc.
Applications:
Ideal for use in apartment complexes, shared housing, home automation systems, large villas and shared office environments.
Specification Sheet
- Click to download: S567 intercom accessories.pdf
- Android 12 operating system
- Two-way audio communication with other units in the network
- Excellent audio-visual intercom experience with four integrated loudspeakers
- Complies with SIP standard for easy integration in every SIP capable PBXes
- Powered by PoE or external source
- Automatically adjusts screen brightness according to the ambient brightness to protect eyes and save energy
- Voice Changer facility to protect vulerable residents
- Built-in smart voice assistant
- Echo Cancellation
- Voice Activation Detection
- Automatic Gain Control
| Description | S567W |
|---|---|
| Screen display | 10.1 Inch capacitive touch screen |
| Loudspeakers | Quad speakers, 8Ω/2W |
| Ethernet Ports | 1xRJ45, 10/100Mbps adaptive |
| Microphone | Dual microphones,-26dB |
| Installation | Wall-mounted & Desktop |
| Working Humidity | 10~90% |
| Working Temperature | -10°C~ +45°C |
| Storage Temperature | -20°C~ +70°C |
| Protocols support | IPv4, IPv6, HTTP,HTTPS,FTP,TFTP, SNMP, DNS, SNTP, RTSP, SRTP,RTP,TCP,UDP, TLS, ICMP, DHCP, ARP |
| Memory | 4GB RAM / 16GB ROM |
| Alarm Inputs | 8 |
| Streaming Formats | H.263 & H.264 |
| Voice Assistant | Recognition accuracy up to 95% |
| Language Support | English |
| Power Supply | PoE or 12v DC external source |
| Dimensions | 279(W) x 165(H) x 23(D) mm |
| Weight (Net) | 0.75kg |
| Weight (Gross) | 1.40kg |
