Inter-M - PMU120N
120W 6 Input Network-streaming Mixer Amplifier
List Price
£655.62
$824.35
€669.14
incl. VAT
Product Description
The InterM PMU120N Mixer Amplifier is the latest network-enabled commercial amplifier from this leading professional audio brand.
This 120W, 6-input Mixer Amplifier features state-of-the-art, built-in media player functions never previously available in an InterM product.
• USB MEDIA PLAYER
The PMU-120N features a built-in USB sound card / media player – allowing playback of MP3 / WMA / WAV audio files directly from a USB media stick (without the need for an audio player device such as CD / MP3 player).
• INTERNET RADIO
The PMU Mixer Amplifier range now features internet radio capabilities – without the need to connect to a PC / smart phone, etc*.
Using a direct network connection to the PMU amplifier, its on-board processor will provide from the almost limitless choice of internet radio channels to be played through the amplifier – making it a fantastically flexible background music solution.
Internet radio connectivity is via a network / LAN / WAN and TCP-IP or RTSP.
(*Internet radio channels are initially chosen and set using a temporary PC / laptop connection and web browser)
• AUDIO-OVER-IP SIGNAL DISTRIBUTION
The PMU120N Mixer Amplifier is also compatible with Inter-M’s new AOE212N Audio-over-Ethernet Transmitter – a brand new PA distribution device which allows for audio content or paging to be distributed over standard network connectivity to one or many receivers / amplifiers in a building, campus or multi-site PA system.
In such a system, the PMU120N acts as both Amplifier and audio-over-IP Receiver, allowing for huge flexibility and control in long distance, multi-zone / multi-site audio distribution.
• ON-BOARD COLOUR DISPLAY
The new PMU Series Amplifiers feature a built-in 2.8” LCD colour display on the front face, displaying operation status, internet radio channel, output level, USB MP3 song title / artist / album / cover art, etc.
• STANDARD AMPLIFIER FUNCTIONS
The PMU120N also includes more ‘conventional’ features, of course; including 5 selectable microphone / line level inputs, telephone input and dual RCAs (stereo-to-mono sum), as well as mini-jack connector to the front of the device for easy connectivity of portable source devices such as iPhone / smart phone, iPod / MP3 player, CD / DVD player, etc.
• ENERGY EFFICIENT
Inter-M’s PMU Mixer Amplifiers feature Switch Mode Power Supplies (SMPS) to ensure greater energy efficiency and reduced power consumption compared with traditional amplifiers.
SMPS also ensures reduced heat dissipation and allows for reduced physical size and weight of the amplifier.
• APPLICATIONS
The PMU120N Mixer Amplifier provides outstanding value-for-money and functionality for installed public address and background music applications. Ideal for a wide variety of commercial environments including bars / pubs, retail outlets, education, restaurants, fitness centers, dance studios and training facilities.
How to choose the right Amplifier:
We have a wide range of 100v line and Low Impedance professional amplifiers available to meet the needs of every type of installation / commercial application.
To help with choosing the correct Mixer Amplifier for the job, please CLICK HERE for our new Inter-M Mixer Amp Comparison Chart.
Please note that for rack-mounting, both the PMU60N & the PMU120N should be used with the BKT-A120N Bracket.
This 120W, 6-input Mixer Amplifier features state-of-the-art, built-in media player functions never previously available in an InterM product.
• USB MEDIA PLAYER
The PMU-120N features a built-in USB sound card / media player – allowing playback of MP3 / WMA / WAV audio files directly from a USB media stick (without the need for an audio player device such as CD / MP3 player).
• INTERNET RADIO
The PMU Mixer Amplifier range now features internet radio capabilities – without the need to connect to a PC / smart phone, etc*.
Using a direct network connection to the PMU amplifier, its on-board processor will provide from the almost limitless choice of internet radio channels to be played through the amplifier – making it a fantastically flexible background music solution.
Internet radio connectivity is via a network / LAN / WAN and TCP-IP or RTSP.
(*Internet radio channels are initially chosen and set using a temporary PC / laptop connection and web browser)
• AUDIO-OVER-IP SIGNAL DISTRIBUTION
The PMU120N Mixer Amplifier is also compatible with Inter-M’s new AOE212N Audio-over-Ethernet Transmitter – a brand new PA distribution device which allows for audio content or paging to be distributed over standard network connectivity to one or many receivers / amplifiers in a building, campus or multi-site PA system.
In such a system, the PMU120N acts as both Amplifier and audio-over-IP Receiver, allowing for huge flexibility and control in long distance, multi-zone / multi-site audio distribution.
• ON-BOARD COLOUR DISPLAY
The new PMU Series Amplifiers feature a built-in 2.8” LCD colour display on the front face, displaying operation status, internet radio channel, output level, USB MP3 song title / artist / album / cover art, etc.
• STANDARD AMPLIFIER FUNCTIONS
The PMU120N also includes more ‘conventional’ features, of course; including 5 selectable microphone / line level inputs, telephone input and dual RCAs (stereo-to-mono sum), as well as mini-jack connector to the front of the device for easy connectivity of portable source devices such as iPhone / smart phone, iPod / MP3 player, CD / DVD player, etc.
• ENERGY EFFICIENT
Inter-M’s PMU Mixer Amplifiers feature Switch Mode Power Supplies (SMPS) to ensure greater energy efficiency and reduced power consumption compared with traditional amplifiers.
SMPS also ensures reduced heat dissipation and allows for reduced physical size and weight of the amplifier.
• APPLICATIONS
The PMU120N Mixer Amplifier provides outstanding value-for-money and functionality for installed public address and background music applications. Ideal for a wide variety of commercial environments including bars / pubs, retail outlets, education, restaurants, fitness centers, dance studios and training facilities.
How to choose the right Amplifier:
We have a wide range of 100v line and Low Impedance professional amplifiers available to meet the needs of every type of installation / commercial application.
To help with choosing the correct Mixer Amplifier for the job, please CLICK HERE for our new Inter-M Mixer Amp Comparison Chart.
Please note that for rack-mounting, both the PMU60N & the PMU120N should be used with the BKT-A120N Bracket.
Specification Sheet
- Click to download: InterM 100vLineComparisonChart_jul2014.pdf
- Click to download: pmu-120n_brochure.pdf
Manual
- Click to download: pmu120n_manl.pdf
- Built-in MP3 / WMA / WAV player. Audio files are accessible via front panel USB input for USB memory stick
- Built-in USB PC sound card allows direct input of PC audio via rear panel USB connector
- Streaming Network Audio input via rear RJ45 connector (for use with InterM AOE-212N)
- On-board Internet Radio via rear RJ45 connector (requires internet connection)
- 2.8 inch colour LCD screen displays operations status, output level, internet radio channel, USB MP3 song/artist/cover art
- Switch Mode Power Supply (SMPS) technology delivers high power output with energy efficient, low power consumption
- 6 input mixer amplifier with 5 microphone / line level selection
- Phantom Power to inputs 1, 2 and 3
- Signal indicator confirms and displays signal present for each input
- Bass and Treble tone control
- Five zone loudspeaker selector switches, allowing for independent or all-zone broadcast
| Description | PMU120N |
|---|---|
| Rated Output Power | 120W @ 100v line, 4Ω |
| Frequency Response (SP OUT/1W output) | 80Hz ~ 15kHz |
| T.H.D @ Rated output 1kHz | < 0.5% |
| S/N @ Rated output | < -78dB |
| Graphic Equaliser (100Hz 330Hz 1kHz 3.3 kHz 10kHz) | ±10dB |
| Input 1~5 | Mic -50dBu/ 2kΩ, Line -10dB/2kΩ |
| Input 6 | 0dBu/ 10kΩ |
| Tel In | 0dBu/ 10kΩ |
| Ext In | 0dBu/ 20kΩ |
| Amp In | 0dBu/47kΩ |
| Mix Out / Impedance | 0dBu/ 10kΩ |
| Speaker output/ Impedance | LOW-Z 22V/4Ω, HIGH-Z 100V/83Ω |
| Operating Temperature | -10°C ~ +40°C |
| Dimensions | 420(W) × 88(H) × 319(D) |
| Weight (Net) | 6.70kg |
| Weight (Gross) | 10.00kg |
