1G 4K60 AV over IP Transmitter with USB & PoE

The CYP IP-9000TX is a powerful 1G 4K60 AV-over-IP Transmitter engineered for demanding professional AV applications. Delivering visually lossless 4K60 (4:4:4) over standard Gigabit networks, the unit supports both unicast and multicast modes—ideal for everything from point-to-point signal extension to large-scale video walls and matrix systems.

This AV encoder offers unmatched flexibility with HDMI loop-through, USB over IP, PoE support, bi-directional IR/RS-232 pass-through, and independent routing of audio/video/control signals. Multicast mode enables efficient, scalable distribution across multiple displays with minimal bandwidth impact, while USB roaming transforms the system into a robust remote KVM solution.

Compatible with Dante Ready™, the IP-9000TX integrates seamlessly with Dante and AES67 audio networks—offering future-ready interoperability and channel expansion. Whether in a control room, digital signage deployment, or enterprise workspace, this transmitter ensures seamless signal delivery and device control.

Key Highlights:

• Supports Ultra HD 4K60 4:4:4 with HDR10, Dolby Vision & HLG

• Less than 1 frame latency at 4K60Hz ensures real-time performance

• Optional integration with IP Master Controller for simplified system-wide control

Example Applications:

• Corporate video matrix and conference room systems

• Digital signage in retail or hospitality

• Video walls in control rooms and transport hubs

• Medical imaging or operating theatres

• Higher education AV distribution

• Secure KVM switch and remote PC access

• Hotel TV systems and convention centres

• Click to download: IP-9000TX_Datasheet_v1.01.pdf

• Click to download: IP-9000TX_PDF-Manual_v1.03.pdf
