CYP - CR-KP5-R
4-Button Keypad Controller & Rotary Dial with push button
Product Description
The CYP CR-KP5-R is a professional-grade keypad controller designed for AV and control system installations where intuitive user interaction and flexible customisation are essential. Featuring four programmable buttons and a precision rotary dial with push action, it brings simple, reliable control to meeting rooms, education spaces, commercial environments and more.
This compact controller combines tactile button operation with a smooth rotary encoder, enabling installers to tailor control workflows for volume, lighting, source selection and automated macros. Powered via PoE and configurable over the network, the CR-KP5-R integrates seamlessly into IP-based control systems.
Ideal for:
This compact controller combines tactile button operation with a smooth rotary encoder, enabling installers to tailor control workflows for volume, lighting, source selection and automated macros. Powered via PoE and configurable over the network, the CR-KP5-R integrates seamlessly into IP-based control systems.
Ideal for:
- Corporate meeting rooms – centralised control of displays, audio, lighting and more
- Education facilities – intuitive operation for staff and students
- Hospitality & commercial spaces – consistent, reliable control in shared environments
- 4 programmable physical buttons
- Rotary encoder with push-action
- Macro support
- Stores up to 128 commands
- Tri-colour LED buttons
- Power over Ethernet (PoE)
- WebGUI and Telnet support
- Scheduling capabilities
| Description | CR-KP5-R |
|---|---|
| PSU | 5V/2.6A |
| Inputs | 1x Phoenix (4 pin) [1x RS-232 local control] |
| Inputs | 1x RJ45 [1x LAN & PoE IP] |
| Weight (Net) | 0.10kg |
| Weight (Gross) | 0.15kg |
