Zenitel - ZIPS-WC
Zenitel IP Speaker Wallmount Cabinet
Login for Pricing
Product Description
The Zenitel Wall Mount IP Speaker is a high-performance PoE-powered network speaker designed for clear, reliable audio in professional environments. Combining built-in amplification with IP connectivity, it delivers scalable audio for public address, security and communication systems.
Clear, Intelligible Audio
Powered by Zenitel Audio Presence technology, the speaker ensures speech is clear and easy to understand. With a maximum output of 103 dB SPL, it provides consistent audio performance across a wide range of environments.
Two-Way Communication
The integrated speaker-as-microphone technology enables full two-way audio through a single device. This supports:
• Announcements and paging
• Talkback communication
• Ambient listening
• Automatic volume adjustment
This makes the speaker suitable for both communication and monitoring applications.
Scalable IP Audio System
Each speaker is individually addressable and monitored over the network. With no need for central amplifiers or traditional speaker loops, the system is easy to scale across buildings, sites or distributed networks.
Simple Installation and Integration
The speaker is powered using Power over Ethernet (PoE), reducing cabling and simplifying installation. Support for ONVIF and SIP protocols allows integration with video management systems, security platforms and third-party applications.
Built for Indoor and Outdoor Use
A durable IP66-rated housing protects against dust and water, making the speaker suitable for both indoor and outdoor environments. Ideal applications include:
• Corporate buildings
• Transport environments
• Data centres
• Public and commercial spaces
Reliable and Easy to Manage
Advanced supervision features allow the speaker to monitor its own status, detect faults and report issues via SNMP or Syslog. Remote configuration and software updates ensure efficient long-term management.
The Zenitel Wall Mount IP Speaker delivers clear audio, flexible deployment and scalable performance for modern IP-based communication systems.
Clear, Intelligible Audio
Powered by Zenitel Audio Presence technology, the speaker ensures speech is clear and easy to understand. With a maximum output of 103 dB SPL, it provides consistent audio performance across a wide range of environments.
Two-Way Communication
The integrated speaker-as-microphone technology enables full two-way audio through a single device. This supports:
• Announcements and paging
• Talkback communication
• Ambient listening
• Automatic volume adjustment
This makes the speaker suitable for both communication and monitoring applications.
Scalable IP Audio System
Each speaker is individually addressable and monitored over the network. With no need for central amplifiers or traditional speaker loops, the system is easy to scale across buildings, sites or distributed networks.
Simple Installation and Integration
The speaker is powered using Power over Ethernet (PoE), reducing cabling and simplifying installation. Support for ONVIF and SIP protocols allows integration with video management systems, security platforms and third-party applications.
Built for Indoor and Outdoor Use
A durable IP66-rated housing protects against dust and water, making the speaker suitable for both indoor and outdoor environments. Ideal applications include:
• Corporate buildings
• Transport environments
• Data centres
• Public and commercial spaces
Reliable and Easy to Manage
Advanced supervision features allow the speaker to monitor its own status, detect faults and report issues via SNMP or Syslog. Remote configuration and software updates ensure efficient long-term management.
The Zenitel Wall Mount IP Speaker delivers clear audio, flexible deployment and scalable performance for modern IP-based communication systems.
Specification Sheet
- Click to download: ZIPSWC IP Cabinet Speaker.pdf
- Zenitel Audio Presence - crystal clear audio
- Weatherproof housing - IP66
- Max output 103 dB SPL (1kHz/1m)
- Ideal for Micro Zone PA and systems that require a limited number of speakers
- Each speaker is individually addressable and monitored
- ONVIF Compatible
- Remote software upgrade and configuration
- Powered from the IP network cable using Power over Ethernet (PoE)
| Description | ZIPS-WC |
|---|---|
| Codecs | G.711, G.722 |
| Frequency range | 200Hz - 7000Hz |
| Driver frequency range | 90 Hz - 20KHz (± 20%) |
| Output Power | 7.5W/30W |
| IP Rating | IP66+67 |
| Mounting | Aluminium, U Shaped Bracket, Painted RAL9010 |
| Connection Cable Size | Ø6-7 mm |
| Max continuous SPL | 99 dBA |
| Max SPL | 103 dBA |
| Dimensions | 160 x 255 x 189 mm |
| Weight (Net) | 2.10kg |
| Weight (Gross) | 0.90kg |
