CYP - PUV-3150TR-UEAO
HDBaseT 3 Full 4K HDMI Transceiver with USB, LAN, PoH, Dual Audio Pathways & HDMI Bypass
Product Description
Delivering flexible AV connectivity for modern professional environments, the CYP PUV-3150TR-UEAO is a highly versatile HDBaseT 3 HDMI transceiver designed for seamless 4K UHD transmission, control, and power - all over a single Cat6a/7 cable.
This compact unit combines the functionality of both a transmitter and a receiver, offering full 4K/60 4:4:4 resolution support, two-way USB 2.0, Ethernet pass-through, dual-directional audio, and HDMI loop-out—making it the ideal solution for dynamic AV installations requiring robust signal distribution and simplified infrastructure.
Whether deployed in corporate conferencing suites, higher education environments, or government control rooms, the PUV-3150TR-UEAO is engineered for demanding, high-traffic AV ecosystems that rely on reliable long-distance signal extension.
Key Features
Applications
This compact unit combines the functionality of both a transmitter and a receiver, offering full 4K/60 4:4:4 resolution support, two-way USB 2.0, Ethernet pass-through, dual-directional audio, and HDMI loop-out—making it the ideal solution for dynamic AV installations requiring robust signal distribution and simplified infrastructure.
Whether deployed in corporate conferencing suites, higher education environments, or government control rooms, the PUV-3150TR-UEAO is engineered for demanding, high-traffic AV ecosystems that rely on reliable long-distance signal extension.
Key Features
- Bi-Directional Audio & USB 2.0 Support
- Full 4K HDR Support via HDBaseT 3
- Integrated LAN and PoH (Power over HDBaseT)
Applications
- Corporate AV Systems: For integrating remote meeting spaces, interactive touch panels, and audio systems with central AV racks.
- Universities & Training Centres: Reliable signal distribution between teaching podiums and projection/display systems.
- Government & Security Rooms: Dual audio and LAN make it ideal for high-reliability command and control applications.
Manual
- Click to download: PUV-3150TR-UEAO_PDF-Manual_v1.01.pdf
- Transceiver mode supports both HDMI transmission and reception over HDBaseT 3
- Dual-direction audio (Analogue IN/OUT + ARC/eARC passthrough) for comprehensive audio routing
- USB 2.0 (host/device) passthrough ideal for KVM and interactive solutions
- HDMI loop-out on the transmitter end for local monitoring
- Long-distance 4K 60Hz 4:4:4 HDR signal transmission up to 100m over Cat6a
- HDBaseT extends video, audio and data over a single Cat.6A/7 cable and can reach distances up to 100m/328ft
- HDBaseT feature support: HD Video and Audio, Gigabit Ethernet, Bi-directional PoH, Bi-directional audio (optical and analogue), and Control (bi-directional USB/IR/RS-232 pass-through)
- 2 USB 2.0 Type-A device ports and 1 USB 2.0 Type-B host port
- Selectable HDMI or HDBaseT input in receiver mode
| Description | PUV-3150TR-UEAO |
|---|---|
| Inputs | 1x HDMI [1x HDMI Uncompressed AV and Data] |
| - | 2x RJ45 [2x LAN Serving] |
| - | 1x 3.5mm Stereo mini-jack [1x Infra Red Receiver] |
| - | 1x RJ45 [1x HDBaseT 3 (shared port - TX mode HDMI & Propriety Data] |
| - | 1x Phoenix (3 pin) [1x RS-232] |
| - | 1x Phoenix (3 pin) [1x Analogue Stereo (L/R) Audio Input] |
| - | 1x Toslink [1x Optical 2 Channel LPCM] |
| - | 1x USB Type B [1x Service Port Propriety Data] |
| - | 2x USB Type A [2x USB pathway Propriety Data] |
| Outputs | 1x HDMI [1x HDMI Uncompressed AV and Data] |
| - | 1x 3.5mm Stereo mini-jack [1x Infra Red Emitter] |
| - | 1x RJ45 [1x HDBaseT 3 (shared port - RX mode in) HDMI & Propriety Data] |
| - | 1x Phoenix (3 pin) [1x Analogue Stereo (L/R) Audio Output] |
| - | 1x Toslink [1x Optical 2 Channel LPCM] |
| POE PSU | PoH |
| PSU | 48V/0.83A |
| Dimensions | 231.5(W) x 25(H) x 108(D) mm |
| Weight (Net) | 0.70kg |
| Weight (Gross) | 1.00kg |
