HDMI/DisplayPort over IP Transceiver with USB Extension

The CYP SDV-FTRX-U is a robust HDMI/DisplayPort AV over IP transceiver designed for ultra-reliable long-distance video, audio, and data transmission over fiber. With support for both transmitter and receiver configurations, this unit enables point-to-point and fully distributed AV matrix solutions via 10GbE fiber infrastructure.

Compatible with HDMI 2.0, DisplayPort, HDCP 2.2, and HDR content, the SDV-FTRX-U supports 4K60 4:4:4 video with near-zero latency, thanks to visually lossless compression. It features integrated USB 2.0 extension (including KVM switching), RS-232, IR, analogue stereo audio I/O, and can function as part of a larger matrix, multiview, or video wall system when used with CYP’s IP Master Controller.

Key Features:

• 4K over Fiber with SFP+ Modules: Transmit and receive uncompressed 4K60 (4:4:4) video up to 30km over single-mode fiber using compatible SFP+ modules.

• Flexible Signal Modes: Can be configured as either transmitter or receiver; ideal for fixed installs or dynamic switching environments.

• USB KVM and Peripheral Support: Three USB 2.0 ports for keyboard, mouse, webcam, or touchscreen use. Supports Simultaneous Mode for multi-host setups.

Perfect for high-bandwidth, long-range AV installations such as:

• Medical and university campuses

• Secure enterprise AV infrastructure

• Broadcast and event spaces

• Government and control room AV systems

• Fibre-heavy smart building integration

• Click to download: SDV-FTRX-U_PDF-Manual_RDV3.pdf
